Performance Radiator for Toyota Land Cruiser (1996-1997) 4.5L Automatic

Heavy-Duty All-Aluminum Performance Radiator for 1996-1997 Toyota Land Cruiser

Primary Function: Direct replacement performance cooling upgrade engineered to eliminate thermal saturation and coolant leaks on high-mileage overland and heavy-towing applications.

The Stock Land Cruiser Thermal Breakdown

Factory 80-series radiators rely on plastic end-tanks crimped to an aluminum or copper-brass core. Decades of thermal cycling make these plastic composite tanks brittle, resulting in stress cracking along the upper tank neck and perimeter crimp seals. Under continuous low-speed crawling or high-load ambient heat, the OEM 2-row configuration suffers from heat soak, elevating coolant and automatic transmission fluid temps beyond safe operating margins.

The Engineering Solution

This drop-in upgrade features 100% TIG-welded aircraft-grade aluminum construction, completely eliminating failure-prone plastic tanks and epoxy joints. The high-density 3-row downflow core measures 16.75" H x 28.65" W, significantly increasing fluid capacity, heat transfer surface area, and airflow dissipation. An integrated heavy-duty automatic transmission fluid cooler utilizes factory-spec M14x1.5 threaded ports to maintain stable gearbox operating temperatures during steep hill climbs and off-camber loads.

Technical Specifications

Compatibility

• 1996 Toyota Land Cruiser 80-Series (FZJ80) 4.5L I6 Gasoline Automatic
• 1997 Toyota Land Cruiser 80-Series (FZJ80) 4.5L I6 Gasoline Automatic
• Note: Does not fit 1998-later Land Cruiser 4.7L V8 models.

The Toyota Durability Standard

Built to withstand extreme corrugated roads and heavy payload demands, this full-aluminum core resists torsional fatigue and provides reliable thermal management under extreme trail and towing conditions.
