Exhaust Tips for Chevrolet Camaro & Pontiac Firebird Trans Am (1997-2002)

T304 Titanium-Finished Dual Exhaust Tips for 1997-2002 Chevrolet Camaro & Pontiac Firebird (LS1/LT1 F-Body)

What It Does: Replaces corroded or undersized factory exhaust tips with high-diameter, double-walled T304 stainless steel units to improve rear-exit aesthetics and resist thermal discoloration.

The Fourth-Generation F-Body Exhaust Shortcomings

The 1997-2002 F-Body platform, while performance-oriented, frequently suffers from premature oxidation of the factory mild-steel exhaust components. From a mechanical standpoint, the stock tips are often thin-walled and undersized, failing to properly fill the rear bumper cutouts of the Z28, SS, and Trans Am trims. Over time, heat soak and exposure to road salt lead to pitting and structural failure at the weld points. Furthermore, standard single-wall tips allow internal exhaust temperatures to reach the outer surface rapidly, causing the chrome finish to yellow or blue under high-load conditions common in the LS1 and LT1 powertrains.

The Engineering Solution

These dual-exit tips are engineered using heavy-duty T304 stainless steel, a material selected for its high chromium and nickel content which provides superior resistance to atmospheric corrosion and acidic exhaust gasses. The construction features TIG (Tungsten Inert Gas) welding, ensuring a high-strength bond that resists cracking under the high-vibration environment of a 5.7L V8. The double-wall design creates an air gap between the inner and outer layers, acting as a thermal barrier to protect the unique titanium finish from heat-induced discoloration. With a 2.5-inch inlet and a total 8.75-inch span, these units provide a precision fit that aligns with the factory exhaust geometry while offering a more aggressive, stealth-like appearance compared to standard mirror-polished steel.

Technical Specifications

Compatibility

• 1997-2002 Chevrolet Camaro (Z28, SS, Base)
• 1997-2002 Pontiac Firebird (Formula, Trans Am, Base)
• Fits both 5.7L V8 (LS1/LT1) and 3.8L V6 (L36) models with 2.5" exhaust piping

The F-Body Muscle Standard

Designed specifically for the American muscle enthusiast, these tips deliver the aggressive profile required to match the output of the LT1 and LS1 Small Block V8s. The TIG-welded T304 construction ensures that the hardware survives the high-velocity airflow and thermal stress of performance driving without compromising the dark-chrome aesthetic.

Common Questions

Will these exhaust tips fit my 1997-2002 Camaro or Firebird Trans Am?
Yes, these tips are built for 1997-2002 Chevrolet Camaro (Z28, SS, Base) and Pontiac Firebird (Formula, Trans Am, Base) models equipped with 2.5-inch exhaust piping.

What are the inlet, outlet, and width dimensions?
Each tip assembly features a 2.5-inch inlet feeding dual 4-inch outlets with a total span of 8.75 inches across the outlets.

Which engines are compatible with these tips?
They fit 1997-2002 F-Body models with the 5.7L V8 (LS1 and LT1) or the 3.8L V6 (L36) running 2.5-inch exhaust tailpipes.

What material and finish are used on these tips?
They are TIG-welded from heavy-duty T304 stainless steel with a double-walled construction and a dark-chrome titanium finish.

How does the double-wall design help prevent heat discoloration?
The double-wall construction creates an insulating air gap between the inner exhaust channel and the outer shell, acting as a thermal barrier to protect the titanium finish from yellowing or bluing under high exhaust temperatures.
