Cold Air Intake for Nissan Xterra (2005-2015) 4.0L Engine

$179.95
$179.95
Free Shipping within USA.
  • Guaranteed Fitment
  • Performance Tested
  • Lifetime Warranty

Want it soon? Order within

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"

Tired of your Nissan Xterra’s factory restrictions holding back its true potential on the trail or highway? Unleash a torrent of power and a commanding engine growl with an intake designed to perform, instantly transforming your driving experience.

Performance Cold Air Intake Kit for Nissan Xterra (2005-2015) 4.0L V6

The factory air intake system on your 2005-2015 Nissan Xterra with the 4.0L V6 engine is engineered primarily for quiet operation and cost-effectiveness, not peak performance. This often means a convoluted, restrictive air box and narrow intake tube that choke your engine’s airflow, limiting horsepower, torque, and throttle response right from the factory floor. This design prevents your VQ40DE engine from breathing freely, especially under demanding conditions.

Our performance cold air intake system is specifically engineered to eliminate these factory bottlenecks. By replacing the stock air box and intake tube with a high-flow, T304 lightweight aluminum piping and an integrated heat shield, this kit delivers a larger volume of cooler, denser air directly to your engine. The result is a more efficient combustion, unlocking significant gains in horsepower and torque, providing a noticeably sharper throttle response, and enhancing your Xterra’s overall capability and driving dynamics.

Why You Need This Upgrade

  • Boosted Power Output: Experience up to a 10% increase in horsepower and torque, translating to more assertive acceleration and improved pulling power for your 4.0L V6.
  • Premium T304 Aluminum Construction: Built from durable, lightweight T304 aluminum tubing, ensuring long-lasting performance and superior heat management compared to stock plastic components.
  • Integrated Heat Shield: A dedicated heat shield effectively isolates the air filter from engine bay heat, guaranteeing a consistent supply of cooler, denser air for optimal combustion.
  • Enhanced Engine Airflow: Replaces narrow, restrictive factory components with an open-induction design, allowing your engine to inhale freely and satisfy its full air demands.
  • Sharper Throttle Response: Eliminates the sluggishness of the OEM intake, providing instant power delivery and a more engaging driving feel when you hit the gas.
  • Improved Fuel Efficiency: Optimizes the air-to-fuel ratio for a more complete and effective burn, potentially leading to better mileage under typical driving conditions.
  • Aggressive Engine Sound: Enjoy a deeper, more pronounced intake growl under acceleration, adding a sporty auditory experience to your Xterra’s performance.

Technical Specifications

Fitment 2005-2015 Nissan Xterra 4.0L V6
Factory Stats Stock: 261 HP / 281 lb-ft
Installation Direct bolt-on using factory mounting points; Est. 1-2 hours (requires battery reset)

Replaces These OEM Applications

Compatible Vehicles:

  • 2005 Nissan Xterra 4.0L V6
  • 2006 Nissan Xterra 4.0L V6
  • 2007 Nissan Xterra 4.0L V6
  • 2008 Nissan Xterra 4.0L V6
  • 2009 Nissan Xterra 4.0L V6
  • 2010 Nissan Xterra 4.0L V6
  • 2011 Nissan Xterra 4.0L V6
  • 2012 Nissan Xterra 4.0L V6
  • 2013 Nissan Xterra 4.0L V6
  • 2014 Nissan Xterra 4.0L V6
  • 2015 Nissan Xterra 4.0L V6

Upgrade Your Nissan Xterra Today

Don’t let a restrictive factory intake hold back your Nissan Xterra’s 4.0L V6 engine. Shop with confidence knowing that PerformanceChipTuning.com delivers the best cold air intake parts with fast shipping and expert support, ensuring your Xterra is ready for any adventure.

Engine Safety Rating
Difficulty

Fitment

Make

Nissan

Engine Size
  • 4.0L

Year
  • 2005
  • 2006
  • 2007
  • 2008
  • 2009
  • 2010
  • 2011
  • 2012
  • 2013
  • 2014
  • 2015

Installation & Tools

The Wrench Time

  • Estimated Time: 45-60 Minutes
  • Difficulty: 3/10 - Basic bolt-on, but requires patience with aging VQ40DE plastics and a delicate Mass Air Flow (MAF) sensor.

Tools You Will Need

  • 10mm socket and ratchet (for battery and factory airbox bolts)
  • 10mm wrench (for the battery terminal)
  • 8mm socket or 5/16-inch nut driver (for hose clamps)
  • #2 Phillips head screwdriver (for factory MAF screws)
  • 3mm or 4mm Allen wrench (for aftermarket MAF hardware)
  • Pliers (for factory spring clamps)
  • Panel popper (for wiring harness clips)
Mechanic’s Pro Tip (The "Gotcha"):
When removing the factory VQ40DE intake tube, be extremely gentle with the plastic crankcase breather hose fitting. After years of heat cycling on this chassis, that plastic is notoriously brittle and will snap off inside the hose if you yank it. Use your pliers to slide the spring clamp back, then twist the hose gently to break the seal before pulling. Furthermore, the factory MAF sensor screws strip easily—use a fresh #2 Phillips bit and apply firm downward pressure before turning.

Phase 1: Removing the Factory Part

  1. Disconnect the Battery: Always start by disconnecting the negative battery terminal using a 10mm wrench to prevent check engine lights on your 2005-2015 Nissan Xterra 4.0L. Tuck the cable safely away from the post.
  2. Unplug the MAF Sensor: Locate the Mass Air Flow sensor on the factory intake tube. Slide the colored locking tab back, press down on the release clip, and pull the connector straight off. Use a panel popper to unclip the wire harness from the airbox lid.
  3. Remove the Factory MAF: Take your Phillips head screwdriver and extract the two screws holding the MAF sensor. Carefully pull the sensor straight up and place it in a clean zip-top bag to prevent contamination. Do not touch the internal wires or element.
  4. Disconnect the PCV Breather: Grab your pliers, squeeze the spring clamp on the crankcase breather hose, and slide it a few inches down the line. Gently twist and pull the hose off the factory intake tube.
  5. Loosen the Clamps: Grab your 8mm socket and loosen the hose clamps at the throttle body and the factory airbox lid. Wiggle the factory tube free and set it aside.
  6. Extract the Factory Box: Use your 10mm socket to remove the single mounting bolt securing the lower airbox to the driver’s side inner fender. Yank the entire assembly straight up to pop it out of the rubber mounting grommets.

Phase 2: Installing the Cold Air Intake for Nissan Xterra (2005-2015) 4.0L Engine

  1. Assemble the Heat Shield: Drop the new aftermarket airbox or heat shield into the factory location. Press the mounting pegs into the OEM rubber grommets and secure the top mounting point using the provided hardware and a 10mm socket.
  2. Install the Silicone Couplers: Slide the provided silicone step-coupler onto the VQ40 throttle body. Slide the hose clamps over the ends and tighten the throttle body side down snugly using your 8mm socket.
  3. Transfer the MAF Sensor: Carefully remove your factory MAF from the bag, ensuring the factory O-ring is still seated properly. Slide it straight into the new intake tube and secure it using the provided hardware (usually requiring a 3mm or 4mm Allen wrench). Do not over-tighten, or you will crack the plastic housing.
  4. Position the Intake Tube: Slide the new intake tube into the throttle body coupler, then attach the air filter end to the heat shield or filter housing. Once properly aligned, tighten all remaining hose clamps with your 8mm socket.
  5. Reconnect the Breather and Wiring: Push the factory crankcase breather hose onto the new intake tube nipple and secure it with the spring clamp using pliers. Plug the MAF sensor harness back in until it clicks, and engage the locking tab.
  6. Initial Startup Procedure: Reconnect the negative battery terminal with your 10mm wrench. Start the engine, but do not touch the gas pedal for 20 seconds. Allow the ECU time to read the new MAF sensor data and adjust to the increased airflow without forcing a stall or triggering a lean code.

Disclaimer: This is a general guide provided for the 2005-2015 Nissan Xterra 4.0L. Always refer to your factory service manual for exact torque specifications and safety procedures.
