Cold Air Intake for Ford Ranger B4000 (2004-2011) 4.0L Engine
Couldn't load pickup availability
- Guaranteed Fitment
- Performance Tested
- Lifetime Warranty
Want it soon? Order within
Optimize Airflow and Throttle Response for the Ford Ranger Cologne V6
Who It’s For: Designed specifically for Ford Ranger and Mazda B4000 owners running the 4.0L Cologne V6 engine. Whether you’re using your truck as a daily workhorse or a weekend trail rig, this intake is for drivers who want better mid-range pull and a more responsive pedal.
The Problem: The factory airbox on the Cologne V6 is built for sound suppression, not performance. It uses a restrictive, corrugated plastic intake tube that creates air turbulence and traps heat. This causes the engine to struggle for breath, especially under load or in high-temperature environments, leading to sluggish acceleration and decreased efficiency.
The Solution: We engineered this cold air intake to replace the narrow factory plumbing with high-flow aluminum piping. By smoothing the path to the throttle body and utilizing a high-velocity cone filter, we significantly reduce intake air temperatures and air resistance. This allows your 4.0L SOHC to breathe freely, correcting the factory design flaws and providing a noticeable bump in power and a deeper engine note.
Why This is the Ultimate Upgrade
- Enhanced Velocity: Mandrel-bent aluminum piping ensures a smooth, consistent air stream, increasing horsepower and torque by up to 10% across the power band.
- Superior Filtration: Features a washable, high-flow blue cone filter that provides exceptional filtration while allowing maximum air volume.
- Direct Bolt-On Fit: No cutting or drilling required. This kit is designed to utilize existing mounting points, allowing for a clean installation in less than 60 minutes with basic hand tools.
Technical Specifications
| Fitment | 2004-2011 Ford Ranger / 2004-2009 Mazda B4000 (4.0L V6) |
| Engine Family | Cologne V6 (SOHC) |
| Factory Ratings | 207 HP & 238 LB-FT Torque |
| Kit Components | 2 Intake Pipes, 5 Hose Clamps, 2 Silicone Couplers, 1 Blue Filter, 1 Breather Hose, 1 Bracket Set |
Compatibility & OEM Reference
Fits the Following Vehicles:
- 2004 Ford Ranger 4.0L SOHC Engine
- 2005 Ford Ranger 4.0L SOHC Engine
- 2006 Ford Ranger 4.0L SOHC Engine
- 2007 Ford Ranger 4.0L SOHC Engine
- 2008 Ford Ranger 4.0L SOHC Engine
- 2009 Ford Ranger 4.0L SOHC Engine
- 2010 Ford Ranger 4.0L SOHC Engine
- 2011 Ford Ranger 4.0L SOHC Engine
- 2004 Mazda B4000 4.0L SOHC Engine
- 2005 Mazda B4000 4.0L SOHC Engine
- 2006 Mazda B4000 4.0L SOHC Engine
- 2007 Mazda B4000 4.0L SOHC Engine
- 2008 Mazda B4000 4.0L SOHC Engine
- 2009 Mazda B4000 4.0L SOHC Engine
The Performance Promise
Buy with confidence. As specialists in V6 truck performance, we know how much difference a breath of cold air makes for the Cologne V6. This kit is backed by our expertise and designed for long-term durability. We recommend disconnecting your battery for 10 minutes post-install to allow the ECU to map for the increased airflow.
Common Questions
Will this cold air intake fit my 2004-2011 Ford Ranger or 2004-2009 Mazda B4000?
Yes, this kit is a direct bolt-on fit for 2004-2011 Ford Ranger and 2004-2009 Mazda B4000 trucks equipped with the 4.0L SOHC Cologne V6 engine.
Will this fit a Ranger or B-Series truck with the 2.3L or 3.0L engine?
This intake kit is engineered specifically for models running the 4.0L SOHC V6 engine.
What components are included in the box?
The kit includes 2 mandrel-bent aluminum intake pipes, 1 washable blue cone air filter, 2 silicone couplers, 5 hose clamps, 1 breather hose, and 1 mounting bracket set.
Does installation require any cutting or drilling?
Installation requires zero cutting or drilling. It bolts directly to factory mounting points in under 60 minutes using basic hand tools.
Do I need to tune my truck after installing this intake?
The factory ECU adjusts automatically. Disconnecting the battery for 10 minutes after installation is recommended so the ECU can map for the increased airflow.
Fitment
Fitment
Installation & Tools
Installation & Tools
DIY Guide: Cold Air Intake for Ford Ranger B4000 (2004-2011) 4.0L Engine for 2004-2011 Ford Ranger 4.0L
Required Tools
- 8mm and 10mm sockets with ratchet
- T20 Torx security bit (for MAF sensor screws)
- Flathead screwdriver or 5/16-inch nut driver
- Needle-nose pliers
Leave the lower factory plastic airbox tray bolted into the fender well. The new open-element cone filter rests directly inside this lower tray to catch cool outside air while shielding it from radiator fan wash.
Phase 1: Factory Component Removal
- Disconnect the negative battery terminal using an 8mm or 10mm wrench to allow the ECU fuel trims to reset.
- Unclip the electrical connector on the Mass Air Flow (MAF) sensor, and carefully pull the PCV breather hose off the factory plastic intake tube.
- Loosen the hose clamp at the throttle body (under the 4.0L SOHC engine cover), unclip the upper airbox lid, and lift the factory intake tube and upper lid assembly out of the truck, leaving the lower airbox tray in place.
- Use a T20 Torx bit to remove the two screws securing the factory MAF sensor to the stock housing, and gently extract the sensor.
Phase 2: Aftermarket Installation
- Join the main curved polished aluminum intake pipe to the shorter straight MAF adapter section using the supplied black silicone coupler and two stainless worm-gear clamps.
- Insert the factory MAF sensor into the machined aluminum boss on the intake tube and secure it using the provided screws.
- Slide the throttle body silicone coupler onto the throttle body inlet, fit the polished intake assembly into place, and clamp the red high-flow cone filter onto the end of the tube so it rests inside the factory lower airbox tray.
- Attach the factory breather hose to the port on the aluminum pipe, reconnect the MAF wiring harness, tighten all hose clamps with a 5/16-inch nut driver, and reconnect the negative battery terminal.
Disclaimer: This is a general guide provided for the 2004-2011 Ford Ranger 4.0L. Always refer to your factory service manual for exact torque specifications and safety procedures.
