Cold Air Intake for Ford Mustang (2015-2017) 5.0L V8 Engine - Black

$159.99
$159.99
Free Shipping within USA.
  • Guaranteed Fitment
  • Performance Tested
  • Lifetime Warranty

Want it soon? Order within

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"

Imagine instant throttle response and a raw, aggressive induction note every time you hit the gas. This essential upgrade liberates your Mustang’s true potential, transforming every drive into an exhilarating experience free from factory limitations.

Performance Cold Air Intake for Ford Mustang (5.0L V8 Coyote)

The stock air induction system on your 2015-2016 Ford Mustang 5.0L V8 is designed with compromises — primarily for noise reduction and cost-efficiency over maximizing engine airflow. This often results in a restrictive airbox and convoluted piping that chokes your powerful Coyote engine, preventing it from breathing freely, especially during high-RPM demands on the track or spirited canyon drives.

This precision-engineered cold air intake system specifically addresses these shortcomings by replacing the factory’s airflow bottlenecks. Utilizing high-grade T304 aluminum piping, it provides a smooth, unobstructed path for a larger volume of cooler, oxygen-rich air directly to your engine. The result is a substantial boost in horsepower and torque, sharper throttle response across the entire RPM range, and a more aggressive V8 growl that truly matches your Mustang’s character.

Why You Need This Upgrade

  • Enhanced Power & Torque: Experience noticeable gains in horsepower and torque, unlocking more of your 5.0L Coyote’s potential for stronger acceleration and improved overall performance.
  • Instant Throttle Response: Eliminate restrictive airflow pathways, significantly reducing intake lag for a more immediate and direct connection between your foot and the engine’s power output.
  • Aggressive Engine Tone: Transform your Mustang’s induction sound with a deeper, more pronounced, and satisfying growl that highlights its performance pedigree without being overwhelming.
  • Optimized Airflow & Efficiency: Ensures a consistent, high-velocity flow of cooler air, which helps optimize the air-to-fuel ratio for a more efficient burn and potentially better fuel economy under normal driving conditions.
  • Superior Filtration: Equipped with an advanced, high-flow performance air filter that not only maximizes airflow but also provides excellent filtration, protecting your engine from harmful contaminants.

Technical Specifications

Fitment 2015-2017 Ford Mustang 5.0L V8
Factory Stats Stock: 435 HP / 400 lb-ft
Installation Moderate / 1-2 Hours

Replaces These OEM Applications

Compatible Vehicles:

  • 2015 Ford Mustang GT 5.0L V8
  • 2016 Ford Mustang GT 5.0L V8

Unleash Your S550 Mustang Today

Don’t let a restrictive stock airbox hold back your 5.0L Coyote. Upgrade to a high-performance cold air intake and feel the difference in power, response, and sound. Shop with confidence knowing that PerformanceChipTuning.com delivers the best Cold Air Intake parts with fast shipping and expert support for your 2015-2016 Ford Mustang.

Engine Safety Rating
Difficulty

Fitment

Make

Ford

Engine Size
  • 5.0L

Year
  • 2015
  • 2016
  • 2017

Installation & Tools

The Wrench Time

  • Estimated Time: 45-60 Minutes
  • Difficulty: 3/10 - Basic hand tools, straightforward bolt-on, but requires strict care with fragile factory plastics and sensors.

Tools You Will Need

  • 10mm socket and ratchet (for airbox mount and battery)
  • 7mm and 8mm nut drivers (for hose clamps)
  • T20 Torx bit (crucial for MAF sensor removal)
  • Needle-nose pliers (for factory spring clamps)
  • Panel popper tool (for wire harness routing clips)
Mechanic’s Pro Tip (The "Gotcha"):
If you’ve spent five minutes on the S550 Coyote forums, you know this chassis has two massive headaches: the factory PCV quick-disconnect fittings and the useless Sound Tube. The grey and green plastic tabs on the factory breather hoses get incredibly brittle from engine heat. Do NOT yank them. Push the tab IN, push the hose forward slightly to release the lock, and then pull back safely. Also, this is the perfect time to do a "Sound Tube Delete"—cap off that firewall grommet so you don’t tear your knuckles up trying to reinstall it.

Phase 1: Removing the Factory Part on your 2015-2017 Ford Mustang 5.0L

  1. Disconnect the Battery: Always start by disconnecting the negative battery terminal using a 10mm wrench to prevent check engine lights.
  2. Disconnect the MAF Sensor: On your 2015-2017 Ford Mustang 5.0L, locate the Mass Air Flow sensor on the factory intake tube. Slide the red locking tab back, press the clip, and gently pull the harness off. Use a panel popper to free the harness wire tie from the airbox.
  3. Remove the PCV and Sound Tube Lines: Carefully depress the grey and green release tabs on the factory PCV hoses and slide them off the intake tube. Use needle-nose pliers to compress the spring clamp on the sound tube and pull it free from the intake.
  4. Loosen the Throttle Body Clamp: Use a 7mm nut driver to loosen the factory hose clamp securing the intake tube to the throttle body.
  5. Extract the Factory Airbox: Remove the single factory retaining bolt on the passenger side fender using a 10mm socket. Lift the entire factory intake assembly straight up and out of the engine bay to pop it off the lower rubber mounting grommets.

Phase 2: Installing the Cold Air Intake for Ford Mustang (2015-2017) 5.0L V8 Engine - Black

  1. Transfer the MAF Sensor: This is the most sensitive step. Use your T20 Torx bit to remove the factory sensor. Do NOT touch the exposed wire element. Carefully seat it into your new Cold Air Intake for Ford Mustang (2015-2017) 5.0L V8 Engine - Black, and secure it with the provided hardware.
  2. Mount the New Heat Shield: Drop the new aftermarket airbox or heat shield into the factory lower grommets. Secure it to the fender using the factory bolt and your 10mm socket.
  3. Install the Intake Tube: Slide the provided silicone couplers onto the throttle body and the new intake tube. Seat the tube, adjust for clearance, and firmly tighten all clamps down using an 8mm nut driver.
  4. Reconnect Hoses and Harness: Snap the factory PCV lines onto the new intake’s aluminum fittings until you hear an audible click. Plug the MAF sensor harness back in and engage the red locking tab. If your kit includes a firewall plug, cap off the sound tube hole.
  5. ECU Relearn and Startup: Reconnect the negative battery terminal with your 10mm wrench. Start the vehicle, but DO NOT touch the gas pedal for 20 seconds. Let the Coyote idle so the ECU can calibrate to the increased airflow without throwing a lean code.

Disclaimer: This is a general guide provided for the 2015-2017 Ford Mustang 5.0L. Always refer to your factory service manual for exact torque specifications and safety procedures.
