Cold Air Intake for Ford F-150 (2004-2008) 5.4L V8 Engine

$129.95
$129.95 $199.95
Free Shipping within USA.
  • Guaranteed Fitment
  • Performance Tested
  • Lifetime Warranty

Want it soon? Order within

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"
Up to 35% off

Dominate the Road: Performance Cold Air Intake for Your Ford F-150 5.4L Triton V8

Who It’s For: Designed specifically for Ford F-150 owners running the Triton V8 engine from 2004 to 2008, whether you’re a daily driver, a weekend warrior, or someone who relies on their truck for serious towing and hauling.

The Problem: The factory intake system on the F-150’s 5.4L Triton V8 was engineered primarily for quiet operation and cost-effectiveness, not peak performance. From my years wrenching on these trucks, I’ve seen firsthand how the stock air box, with its convoluted tubing and restrictive paper filter, chokes the powerful Triton V8, especially when you’re asking for maximum power – whether it’s hauling a heavy load, towing a trailer, or just pushing it on the highway. It limits the engine’s ability to truly breathe, leading to sluggish throttle response and leaving horsepower and torque on the table.

The Solution: We engineered this cold air intake system to directly address these factory design flaws of the Triton V8, delivering reliable, optimized performance. By replacing the restrictive OEM components with a high-flow, direct-path design, this system ensures your 5.4L Triton V8 gets a consistent, massive charge of cool, oxygen-rich air. This isn’t just an upgrade; it’s giving the engine back the power and responsiveness it should have had from the factory, making your F-150 feel more capable and eager to perform.

Why This is the Ultimate Upgrade

  • Peak Power & Instant Response: This system transforms your F-150’s performance. By maximizing the volume of cooler, oxygen-rich air reaching the combustion chambers, you’ll feel a significant bump in horsepower and torque across the RPM range. The lag you felt with the factory setup? Gone. Expect sharper throttle response, stronger pull for towing, and a more aggressive growl from that Triton V8.
  • Superior Durability & Filtration: Crafted from high-grade T-304 aluminum, this intake isn’t just about flow; it’s built to last. The integrated thermal heat shield ensures your engine only pulls in cold air, even under heavy load or in scorching temperatures. Paired with a high-flow, washable performance air filter, you get optimal filtration, protecting your engine while delivering maximum airflow for years to come.
  • Hassle-Free Installation & PCM Optimization: I’ve installed my share of these kits, and this one is designed for a straightforward, direct bolt-on fitment. All the necessary silicone couplers, vacuum lines, clamps, and hardware are included, making for a smooth weekend project. And don’t forget that crucial step: disconnect your battery’s negative terminal after install for a few minutes. This allows your F-150’s PCM to ‘relearn’ and adapt to the increased airflow, ensuring you get every ounce of power and efficiency this upgrade provides right from the start.

Technical Specifications

Fitment 2004–2008 Ford F-150
Engine Family Triton V8
Factory Ratings 300 HP & 365 lb-ft Torque (5.4L 3V Triton)
Part Numbers Not specified in product data.

Compatibility & OEM Reference

Fits the Following Vehicles:

  • Ford F-150 (2004-2008 models with 5.4L V8 engine)

Interchange Part Numbers:

Not specified in product data.

The Performance Promise

Buy with confidence. Backed by real automotive experts and fast shipping.

Engine Safety Rating
Difficulty

Fitment

Make

Ford

Engine Size
  • 5.4L

Year
  • 2004
  • 2005
  • 2006
  • 2007
  • 2008

Installation & Tools

The Wrench Time

  • Estimated Time: 45-60 Minutes
  • Difficulty: 3/10 - Basic hand tools required, but extreme care is needed around brittle factory 3V Triton plastics.

Tools You Will Need

  • 8mm, 10mm, and 13mm sockets with a 1/4-inch ratchet and extension
  • T20 Torx driver (for the factory MAF sensor screws)
  • Flathead screwdriver or panel popper (for wire harness clips)
  • 3mm Allen wrench (for aftermarket MAF hardware)
  • 10mm combination wrench (for the battery terminal)
Mechanic’s Pro Tip (The "Gotcha"):
The 2004-2008 Ford F-150 5.4L 3V Triton engines are notorious for brittle PCV breather connections. When removing the hard plastic CCV (Crankcase Ventilation) line near the throttle body, do NOT force it with a screwdriver. Depress the locking tab fully before pulling. If it feels stuck, push inward first, squeeze the tab, then pull outward. Breaking this means an annoying trip to the dealership. Secondly, NEVER touch the delicate internal wire on the MAF sensor during the transfer.

Phase 1: Removing the Factory Part

  1. Disconnect the Battery: Always start by disconnecting the negative battery terminal using a 10mm wrench to prevent check engine lights and to force the ECU to reset its fuel trims for the 2004-2008 Ford F-150 5.4L engine.
  2. Unplug the MAF Sensor: Slide the red locking tab back, press the release clip, and disconnect the MAF wiring harness from the factory airbox. Unclip the wire loom from the plastic housing using a panel popper.
  3. Disconnect the PCV Line: Gently squeeze the locking tab on the CCV hose near the throttle body and pull straight back to release it from the factory intake tube.
  4. Remove the Factory Intake Tube and Resonator: Use an 8mm socket to loosen the hose clamp securing the intake tube to the TB (Throttle Body). Unbolt the massive factory resonator bracket using a 10mm socket and lift the entire bulky assembly off the engine. You will immediately notice how much easier it is to access your throttle body.
  5. Extract the Factory Airbox: Remove the four mounting bolts securing the lower airbox to the driver side fender well using a 10mm socket. Lift the box out. Finally, use a T20 Torx driver to carefully remove the two factory screws holding the MAF sensor. Pull the MAF out straight and set it safely aside on a clean microfiber towel.

Phase 2: Installing the Cold Air Intake for Ford F-150 (2004-2008) 5.4L V8 Engine

  1. Assemble and Mount the Heat Shield: Pre-assemble the aftermarket heat shield using the supplied rubber edge trim. Mount the new shield into the factory airbox fender location using your 10mm socket and the supplied hardware.
  2. Transfer the MAF Sensor: Carefully slide the factory MAF sensor into the new intake tube. Ensure the sensor orientation matches the factory direction (look for the airflow arrows pointing toward the throttle body). Secure it using a 3mm Allen wrench and the provided button-head screws. Do not overtighten, or you will strip the threads.
  3. Mount the Silicone Couplers: Slide the silicone step-down coupler onto the Throttle Body and the straight coupler onto the new air filter adapter. Slip the hose clamps over the couplers but do not lock them down yet.
  4. Install the New Intake Tube: Thread the new intake tube into the heat shield first, then seat the opposite end into the throttle body coupler. Once everything is aligned and free from rubbing against any metal brackets, lock it down by tightening all hose clamps with your 8mm socket.
  5. Reconnect the PCV and Harness: Push the factory CCV hose onto the new aluminum nipple on the intake tube until it clicks securely. Reconnect the MAF sensor harness and push the red locking tab back in to secure the connection.
  6. Final Check and ECU Learn: Reconnect the negative battery terminal using your 10mm wrench. Start the engine. Do not touch the gas pedal for 20 seconds while the ECU calibrates the idle air volume to the new, higher flow rate. Check for any whistling sounds indicating a vacuum leak.

Disclaimer: This is a general guide provided for the 2004-2008 Ford F-150 5.4L. Always refer to your factory service manual for exact torque specifications and safety procedures.
