Cold Air Intake for BMW 328i E90 E92 E93 (2007-2012) 3.0L L6 Engine

Out of stock
$229.95
$229.95
Free Shipping within USA.
  • Guaranteed Fitment
  • Performance Tested
  • Lifetime Warranty

Want it soon? Order within

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"
Sorry, it's out of stock.

But we can let you know when it's back in.

Sold out

Optimize Airflow and Sound for Your BMW 328i N52 Engine

Who It’s For: Designed specifically for 2007-2012 BMW 328i owners running the naturally aspirated N52 engine family. This is the ideal upgrade for enthusiasts looking to improve throttle response and hear that classic BMW inline-six induction note.

The Problem: The factory air box on the N52 is built for silence, not speed. It uses a restrictive, thick paper filter and accordion-style plastic piping that creates significant air turbulence. This "muffled" design prevents the engine from breathing efficiently during aggressive driving and robs the driver of the visceral engine sound BMW is known for.

The Solution: This Cold Air Intake replaces the restrictive stock assembly with high-flow T6061 aluminum piping and a washable stainless steel mesh filter. We included a dedicated heat shield to mitigate engine bay soak, ensuring that your N52 draws a cooler, denser air charge for more consistent power delivery across the entire RPM range.

Why This is the Ultimate Upgrade

  • Enhanced Induction Sound: Replaces the quiet stock baffles with a smooth aluminum pipe that lets the N52 engine’s natural growl shine under load.
  • High-Flow Filtration: The included stainless steel fine mesh filter is washable and reusable, providing superior airflow compared to standard paper filters without the need for frequent replacements.
  • Optimized Thermal Management: Features a custom-fit heat shield to isolate the filter from the radiant heat of the engine block, keeping intake temperatures lower.

Technical Specifications

Fitment 2007-2012 BMW 328i (E90, E91, E92, E93)
Engine Family N52 3.0L Inline-6
Factory Ratings 230 HP & 200 lb-ft Torque
Materials T6061 Aluminum Piping / Stainless Steel Mesh Filter

Compatibility & OEM Reference

Fits the Following Vehicles:

  • 2007-2012 BMW 328i E90 Sedan (3.0L L6)
  • 2007-2012 BMW 328i E91 Wagon (3.0L L6)
  • 2007-2012 BMW 328i E92 Coupe (3.0L L6)
  • 2007-2012 BMW 328i E93 Convertible (3.0L L6)

Interchange Part Numbers:

E90, E91, E92, E93, N52B30, T6061-BMW-328

The Performance Promise

Buy with confidence. This kit includes all necessary reducers, high-pressure hoses, and mounting accessories for a straightforward installation. Backed by real automotive expertise to ensure your BMW performs at its peak.

Fitment

Make

BMW

Engine Size
  • 3.0L

Year
  • 2007
  • 2008
  • 2009
  • 2010
  • 2011
  • 2012

Installation & Tools

The Wrench Time

  • Estimated Time: 45-60 Minutes
  • Difficulty: 3/10 - Straightforward driveway bolt-on with basic hand tools.

Tools You Will Need

  • 10mm socket and ratchet (for battery terminal & OEM airbox mounting bolts)
  • T20 Torx driver (for Mass Air Flow / MAF sensor retention screws)
  • T25 Torx driver (for front air scoop and radiator support ducting)
  • Flathead screwdriver or 6mm/7mm nut driver (for intake hose clamps)
  • Trim panel popper or precision pick (for wiring harness locking tabs)
Mechanic’s Pro Tip (The "Gotcha"):
On the N52/N51 engine found in the 2007-2012 BMW 3 Series 3.0L, the factory crankcase breather hose attached to the back of the intake elbow becomes extremely brittle from engine heat cycles. Squeeze the ribbed quick-release collar evenly on both sides with your fingertips—never pry it with a screwdriver or twist the hose, or the corrugated neck will snap, resulting in an unmetered vacuum leak and lean codes (P0171/P0174).

Phase 1: Removing the Factory Part

  1. Disconnect the Battery: Open the trunk and use a 10mm wrench to disconnect the negative battery terminal to safeguard your DME and prevent stored MAF fault codes.
  2. Unplug the MAF Sensor: Locate the Mass Air Flow sensor on the factory intake elbow. Slide the gray locking tab back and depress the release clip with your thumb or a precision pick to disconnect the wiring harness.
  3. Remove the Fresh Air Snorkel: Using a T25 Torx driver, remove the two screws securing the front air intake duct to the top of the radiator core support, then pull the duct forward and out.
  4. Disconnect the Breather Line: Locate the rear PCV breather pipe attached to the rear of the intake boot. Squeeze the sides of the plastic quick-connect ring and gently pull it straight off the fitting.
  5. Loosen the Throttle Body Clamp: Loosen the OEM hose clamp connecting the intake accordion tube to the throttle body using a flathead screwdriver or 6mm socket.
  6. Extract the Factory Airbox: Remove the two 10mm mounting bolts holding the OEM airbox to the driver-side inner fender bracket. Lift the entire airbox assembly straight up to pop the lower mounting pins free from their rubber isolator bushings.

Phase 2: Installing the Cold Air Intake

  1. Transfer the MAF Sensor: Using a T20 Torx driver, remove the two factory screws holding the MAF sensor into the OEM airbox housing. Delicately pull the sensor straight out without touching the exposed platinum wire grid. Insert the sensor into the new intake tube bung, ensuring the internal rubber O-ring seats squarely, and secure it with the provided hardware.
  2. Install the Heat Shield: Position the aftermarket heat shield into the engine bay, aligning its bottom mounting prongs with the factory lower rubber chassis grommets on your 2007-2012 BMW 3 Series 3.0L. Secure the bracket using the factory 10mm bolts.
  3. Mount the Coupler & Intake Pipe: Slide the silicone intake coupler over the throttle body inlet and snug the clamp loosely using a 7mm nut driver. Insert the new intake tube into the coupler, align the PCV breather port, and reconnect the factory breather line until it audibly clicks into place.
  4. Fit the Cone Filter & Secure Clamps: Install the high-flow air filter over the end of the intake pipe inside the heat shield area. Ensure there is at least a 1/2-inch gap between the filter and any chassis metal to prevent rattle, then torque all hose clamps down firmly with an 8mm nut driver or flathead screwdriver.
  5. Reconnect and Initial DME Calibration: Plug the MAF wiring harness back in until the latch clicks. Reconnect the negative battery terminal with a 10mm wrench. Start the engine and do not touch the gas pedal for at least 20 to 30 seconds; allow the engine to idle smoothly so the DME can calibrate to the increased airflow volume.

Disclaimer: This is a general guide provided for the 2007-2012 BMW 3 Series 3.0L. Always refer to your factory service manual for exact torque specifications and safety procedures.

Warranty

All products are backed by our Limited Lifetime Warranty. We stand by our quality. [See terms]
