Wake up your 5.0L Coyote V8 with a high-flow intake system that delivers sharper throttle response, increased airflow, and a deeper engine note. Built for the 2011–2014 F-150—more air means more power when you need it.

Let Your Coyote Breathe

The 2011–2014 F-150 with the 5.0L Coyote V8 is a workhorse, but Ford's factory airbox was designed for quiet operation and emissions compliance—not maximum airflow. If you've towed a heavy trailer uphill or pushed your truck hard on the highway, you've felt the limitations of that restrictive intake path.

This cold air intake replaces the baffled factory airbox with a streamlined, high-flow design that allows your Coyote to pull in more oxygen-rich air. The result is improved throttle response, better power delivery across the RPM range, and a more aggressive intake tone. Whether you're hauling equipment, merging into traffic, or just enjoying the drive, this intake makes your F-150 feel more capable and responsive.

Performance Benefits

  • Increased Airflow: High-flow piping reduces restriction and turbulence, allowing the 5.0L to breathe freely and produce more power.
  • Sharper Throttle Response: More direct air path means instant feedback when you press the pedal—no lag, just go.
  • Better Towing Performance: Improved volumetric efficiency helps maintain power under load, especially during heavy hauling or steep climbs.
  • Aggressive Sound: Adds a deep, purposeful intake tone that matches the character of the Coyote V8.
  • Washable Filter: Premium reusable filter provides long-term value and excellent engine protection—just clean and reinstall.

Fitment

  • 2011–2014 Ford F-150 5.0L V8 (Coyote Engine)
  • Compatible with both automatic and manual transmissions

Important Notes

  • Off-Road Use Only: This product is not CARB-compliant and is intended for off-road or racing applications.
  • Professional Installation Recommended: While installation is straightforward, professional installation ensures proper fitment and optimal performance.

Installation Tip

Before starting installation, disconnect the negative battery cable. This allows the ECU to reset and adapt to the increased airflow and cooler intake temperatures. Always ensure the engine is completely co

Engine Safety Rating
Difficulty

Fitment

Make

Ford

Engine Size
  • 5.0L

Year
  • 2011
  • 2012
  • 2013
  • 2014

Installation & Tools

The Wrench Time

  • Estimated Time: 45-60 Minutes
  • Difficulty: 3/10 - Basic hand tools, but patience is required with brittle factory plastic hose fittings on the Coyote engine.

Tools You Will Need

  • 8mm and 10mm sockets (with a ratchet and extension)
  • 13mm socket (for the factory lower airbox bolt)
  • T20 Torx bit (for the factory MAF sensor)
  • Flathead screwdriver (for hose clamps)
  • Panel popper tool (to safely remove the factory air scoop push-pins)
Mechanic’s Pro Tip (The "Gotcha"):
The F-150 forum community knows the Gen 1 Coyote 5.0L runs hot under the hood. The factory PCV and EVAP breather lines connect to the intake tube using plastic quick-disconnects with gray and green locking tabs. After years of heat cycles, these bake and become incredibly brittle. Do not pry them with a flathead screwdriver! Gently squeeze the tabs with your fingers, push in slightly, wiggle, and pull. If they fight you, spray a little silicone lube to help them release so you don’t end up buying a $50 replacement harness from Ford.

Phase 1: Removing the Factory Part

  1. Disconnect the Battery: Always start by disconnecting the negative battery terminal using a 10mm wrench to prevent check engine lights while we unplug engine sensors.
  2. Remove the MAF Sensor: Locate the Mass Air Flow (MAF) sensor on the factory airbox lid. Unplug the grey harness connector. Use a T20 Torx bit to remove the two factory screws. Carefully pull the sensor straight up and out. Place it in a safe, clean spot. Do not touch the delicate internal wire!
  3. Disconnect the Breather Lines: Locate the two hoses attached to the factory intake tube. Squeeze the quick-release tabs firmly with your fingers and pull them straight off the nipples. Tie them back out of the way.
  4. Loosen the Clamps: Grab your 8mm socket or flathead screwdriver and loosen the hose clamps at the throttle body and the airbox lid. Wriggle the factory intake tube free and remove it.
  5. Pull the Factory Airbox: Use your panel popper tool to pop out the plastic push-pins holding the factory air scoop to the radiator core support. Remove the single 13mm bolt securing the lower airbox to the inner fender, then lift the entire factory assembly out of the engine bay.

Phase 2: Installing the Cold Air Intake for Ford F-150 (2011-2014) 5.0L V8 Engine Blue

  1. Assemble the Heat Shield: Put together the new aftermarket heat shield and press on the supplied rubber edge trim. Drop the assembly into the engine bay where the factory airbox sat and secure it to the fender well using your 13mm socket and the factory bolt.
  2. Transfer the MAF Sensor: Carefully insert your factory MAF sensor into the new blue intake tube. Secure it using the supplied aftermarket hardware (usually Allen head bolts). Tighten them until snug—do not overtighten or you will crack the plastic mounting flange.
  3. Install the Couplers: Slide the provided silicone couplers onto the throttle body and the new heat shield pass-through. Slide the loose hose clamps over them, but don’t tighten them down just yet.
  4. Position the Intake Tube: Drop the new blue intake tube into the silicone couplers. Reconnect the factory EVAP and PCV breather lines to the new aluminum or plastic fittings on the tube. Push them on firmly until you hear a definitive click.
  5. Lock it Down and Relearn: Adjust the tube for proper clearance away from coolant hoses, then lock down all hose clamps using your 8mm socket. Reconnect the MAF sensor harness. Reconnect the battery terminal with your 10mm wrench. On the first startup, the vehicle gas pedal should not be touched for a 20 seconds until the ECU adjusts to the new airflow volume.

Disclaimer: This is a general guide provided for the 2011-2014 Ford F-150 5.0L. Always refer to your factory service manual for exact torque specifications and safety procedures.
