Aluminum Radiator for Mercury Mountaineer (2006-2010) 4.0L 4.6L

Heavy-Duty 3-Row Aluminum Radiator for 2006-2010 Mercury Mountaineer

What it Does: Upgrades the factory cooling circuit with a brazed 3-row all-aluminum core engineered to maximize heat rejection and withstand sustained thermal loads during heavy towing or extreme ambient driving.

The Stock Mountaineer Cooling Deficiencies

Factory U251 platforms rely on OEM radiators manufactured with stamped aluminum cores crimped to composite plastic end-tanks. Over continuous heat cycling, disparate expansion rates between the aluminum core and plastic tanks compromise the internal elastomer O-ring seals, precipitating seam failure and coolant loss. Furthermore, the stock core volume easily heat-soaks when hauling or driving in hot climates, leaving both the 4.0L Cologne and 4.6L Modular powertrains prone to elevated operating temperatures.

The Engineering Solution

This direct-replacement unit utilizes a 100% TIG-welded aluminum structure, replacing failure-prone plastic tanks with durable aluminum side tanks. The high-density, brazed 3-row tube-and-fin configuration significantly expands core fluid volume and heat dissipation surface area. Engineered to OEM DPI 2952 geometry, it features factory-correct mounting locations, inlet/outlet barb sizing, and an integrated transmission cooler loop to ensure drop-in installation without front-end modifications.

Technical Specifications

Compatibility

• 2006 Mercury Mountaineer (4.0L V6 / 4.6L V8)
• 2007 Mercury Mountaineer (4.0L V6 / 4.6L V8)
• 2008 Mercury Mountaineer (4.0L V6 / 4.6L V8)
• 2009 Mercury Mountaineer (4.0L V6 / 4.6L V8)
• 2010 Mercury Mountaineer (4.0L V6 / 4.6L V8)

The Mercury Towing & Durability Standard

Engineered to handle severe duty cycles, this all-metal unit provides the thermal margin necessary to protect transmission and engine internals under high load, trailer towing, and harsh fleet usage.
