Radiator for Chrysler Town & Country (2005-2007) 3.3L 3.8L

Direct-Fit Aluminum Replacement Radiator for 2005-2007 Chrysler Town & Country (RS)

What it Does: The Direct-Fit Aluminum Replacement Radiator restores factory-spec thermal regulation on the 2005-2007 Town & Country by dissipating high engine heat loads to prevent severe overheating and coolant loss.

The Stock Chrysler Town & Country Heat Dissipation Failure

The factory radiator on the RS chassis platform is prone to thermal fatigue over extended mileage. The stock glass-reinforced plastic end tanks are mechanically crimped to the core using elastomeric O-rings. Through thousands of thermal expansion cycles and continuous operating pressures of 16 to 18 psi, the polymer embrittles, leading to stress fractures at the upper hose inlet and weeping crimp seals. This causes internal pressure drops, boiling coolant, and dangerous heat soak on the EGA 3.3L and EGH 3.8L pushrod V6 engines during sustained highway towing or heavy stop-and-go traffic.

The Engineering Solution

Engineered as an exact drop-in replacement, this radiator features a 15-15/16 x 30-1/4 x 1-inch brazed aluminum core designed for maximum thermal conductivity. High-density louvered aluminum fins enhance turbulent airflow to extract heat rapidly from the internal tubes without restricting core air passage. Heavy-duty reinforced end tanks are clamped using high-strength crimp tabs over high-grade synthetic gaskets, directly resolving the cracking points of OEM unit 4677692AA (interchange 2795). Each unit undergoes 100% pneumatic leak testing to verify structural integrity under load.

What's Included

• 1 Replacement Radiator Assembly

Technical Specifications

Compatibility

• 2005 Chrysler Town & Country 3.3L V6 Automatic Transmission
• 2005 Chrysler Town & Country 3.8L V6 Automatic Transmission
• 2006 Chrysler Town & Country 3.3L V6 Automatic Transmission
• 2006 Chrysler Town & Country 3.8L V6 Automatic Transmission
• 2007 Chrysler Town & Country 3.3L V6 Automatic Transmission
• 2007 Chrysler Town & Country 3.8L V6 Automatic Transmission

Frequently Asked Questions & Fitment Warnings

Does this fit the RS Town & Country?

Yes, this is a direct fit for the 2005-2007 Chrysler Town & Country equipped with the 3.3L EGA or 3.8L EGH V6 engine and automatic transmission.

Do I need to bleed the cooling system after replacement?

Yes, thoroughly burping and bleeding all air pockets from the cooling passages is required to prevent localized head hot spots and ensure accurate thermostat operation.

The Chrysler Reliability Standard

Engineered to handle the rigorous demands of family transport and extended vacation towing, this radiator provides the robust cooling capacity needed to protect automatic transmissions and V6 drivetrains from severe heat degradation.
